Chemical BKS BKW Carbon Steel Seamless Tubes For Petroleum DIN 17175 19Mn5 15Mo3

China Chemical BKS BKW Carbon Steel Seamless Tubes For Petroleum DIN 17175 19Mn5 15Mo3 supplier
Chemical BKS BKW Carbon Steel Seamless Tubes For Petroleum DIN 17175 19Mn5 15Mo3 supplier Chemical BKS BKW Carbon Steel Seamless Tubes For Petroleum DIN 17175 19Mn5 15Mo3 supplier

Large Image :  Chemical BKS BKW Carbon Steel Seamless Tubes For Petroleum DIN 17175 19Mn5 15Mo3

Product Details:

Place of Origin: Jiangsu China (Mainland)
Brand Name: JIANGSU HUACHENG
Certification: ISO9001 14001 BV TUV PED DNV etc
Model Number: HC

Payment & Shipping Terms:

Minimum Order Quantity: 5MT
Packaging Details: Exporting package/wooden box package/Or per customers’ requirement
Delivery Time: 25~35days
Payment Terms: 30%T/T in advance or 100% L/C at sight
Supply Ability: 8000MT/Month
Contact Now
Detailed Product Description
Application: Boiler, Construction, Chemical, Medical Equipment, Boiler Heat, Exchanger, Gas Metallurgy Delivery Condition: BK, BKS, BKW, NBK, GBK
Grade: 19M, T4, T5, T9, T11, T22, T2, T12, T23, T91, T92, P2, P9, P12, P22, P11, P92, P91, P5, P1, St35, ST45.8, ST35.8, St45, St52 Product Name: Seamless Carbon Steel Tube, Seamless Steel Tubes
Section Shape: Round Standard: DIN 17175, JIS G3461, DIN1626, DIN1629
Surface Treatment: Varnish, Galvanized Technique: Seamless

Chemical BKS BKW Carbon Steel Seamless Tubes For Petroleum DIN 17175 19Mn5 15Mo3



Quick Detail:



Standard: DIN 17175

Grade:ST35.8,ST45.8,19Mn5,15Mo3,13CrMo44,10CrMo910,12CrMo195,

X12CrMo91,X20CrMoV121,ect
Size:(mm)
Out Dimensions: 6 mm ~ 350 mm
Wall Thickness: 0.8 mm ~30mm
Length: Fixed(6m,9m,12,24m) or normal length(5-12m)





Description:



Type

DIN 17175

Pipe Size

6 mm ~ 350 mm

Wall Thickness

0.8 mm ~30mm

Length

5.8m,5.85m,6m,11.8m,12m   Random length: 5-24m

Standard

DIN 2448,DIN1626,DIN17175, DIN1629

ASME B36. 10M-1996,API 5L

JIS G3461, JIS G3456, JIS G3452,JIS G3454,JIS G3455,JIS G3457,

Material

ST37.0,ST35.8,St37.2,St35.4/8,St42,St45,St52,St52.4

A53B, A106B, API 5L B,X42,X46,X52,X60, X65

STP G38,STP G42,STPT42,STB42,STS42,STPT49,STS49

Application

petroleum, construction ,shipbuilding, smelting, aviation, power, foodstuff, papermaking, chemical, medical equipment, boiler heat, exchanger, gas metallurgy, etc.

Surface

Hot galvanized, Cold galvanized, Painted black, varnish paint, anti rust oil, 3PE, or as per customers' requirements

Package

Steel strips bundled, Woven bag packed, Plastic caps on both ends, or as per customers' requirements.

Certificate

ISO9001:2008, SGS,BV, etc

Advantages

1.High quality and prompt delivery

2.Competitive price and attentive services

3.Reliable partner





Chemical Composition:



STANDARD

    GRADE

CHEMICAL COMPOSITION

C

Si

Mn

P,S

Cr

Mo

DIN 17175

St35.8

≤0.17

0.10-0.35

0.40-0.80

≤0.030

/

/

St45.8

≤0.21

0.10-0.35

0.40-1.20

≤0.030

/

/

15Mo3

0.12-0.20

0.10-0.35

0.40-0.80

≤0.030

/

0.25-0.35

13CrMo44

0.10-0.18

0.10-0.35

0.40-0.70

≤0.030

0.70-1.10

0.45-0.65

10CrMo910

0.08-0.15

≤0.50

0.40-0.70

≤0.030

2.00-2.50

0.90-1.20





Mechanical properties:



STANDARD

    GRADE

Tensile Strength(Mpa)

Yield Strength(Mpa)

elongation (%)

DIN 17175

St35.8

360-480

≥235

≥25

St45.8

410-530

≥255

≥21

15Mo3

450-600

≥270

≥20

13CrMo44

440-590

≥290

≥20

10CrMo910

450-600

≥280

≥18





Properties in BK/BKW/BKS/GBK/NBK:



Steel grade

BK

BKW

BKS

 GBK

 NBK

Tensile

Rm
N/mm
min

Elong-ation

%
min

Tensile Rm
N/mm
min



Elong-ation

%
min

Tensile Rm
N/mm
min

Yield ReH
N/mm
min



Elong-ation

%
min

Tensile Rm
N/mm
min



Elong-ation

%
min

Tensile Rm
N/mm
min

Yield ReH
N/mm
min



Elong-ation

%
min

St35

480

6

420

10

420

315

14

315

25

340-470

235

25

St45

580

5

520

8

520

375

12

390

21

440-570

235

21

St52

640

4

580

7

580

420

10

490

22

490-630

355

22





Main Products / Seamless steel tubes for high pressure boilers:



Steel grade

Standard

Application

20G,20MnG,25MnG,

15CrMoG,12Cr2MnG,

12Cr1MnVG,

12Cr2MoWVTiB,1

0Cr9Mo1VNb,ect

GB5310

Seamless steel tubes for

manufacturing high pressure

and higher pressure steam boilers

and piping

SA106GrB,SA106GrC,SA210GrC,

SA210GrA1,ect

ASME SA-106/SA-106M

ASME SA210/SA-210M

T11,T12,T22,T23,T91,T92,ect

ASME SA-213/SA-213M

ST35.8,ST45.8,15Mo3,13CrMo44,

10CrMo910,X20CrMoV121,ect

DIN17175

P11,P12,P22,P5,P9,P23,P91,P92,ect

ASME SA335/SA-335M

P195GH,P235GH,P265GH,16Mo3,

10CrMo9-10,15NiCuMoNb5-6-4,

X10CrMoVNb9-1,ect

EN10216





Applications:



Mainly usd for petroleum, construction ,shipbuilding, smelting, aviation, power, foodstuff, papermaking, chemical, medical equipment, boiler heat, exchanger, gas metallurgy, etc.





Competitive Advantage:



Huacheng Industry Pipe Making Corporation

Asia Leading Steel Pipe & Tube Manufacturer with more than 250,000Tons/Year, >60% shipped to more than 35 Countries.We aims at manufacturing quality pipes & tubes with reasonable and competitive price, good quality for our global customers.





Factroy Pictures:

Chemical BKS BKW Carbon Steel Seamless Tubes For Petroleum DIN 17175 19Mn5 15Mo3



Pipe & Tube Processing

Chemical BKS BKW Carbon Steel Seamless Tubes For Petroleum DIN 17175 19Mn5 15Mo3

Factory Equipments:

Chemical BKS BKW Carbon Steel Seamless Tubes For Petroleum DIN 17175 19Mn5 15Mo3



Production Line:

Chemical BKS BKW Carbon Steel Seamless Tubes For Petroleum DIN 17175 19Mn5 15Mo3

Quality Control:



Chemical BKS BKW Carbon Steel Seamless Tubes For Petroleum DIN 17175 19Mn5 15Mo3



Steel Pipe & Tube Application:

Chemical BKS BKW Carbon Steel Seamless Tubes For Petroleum DIN 17175 19Mn5 15Mo3

Package:

Export Standard / Wooden Box

Chemical BKS BKW Carbon Steel Seamless Tubes For Petroleum DIN 17175 19Mn5 15Mo3

Main Certificates:

PED ISO BV TUV etc.

Chemical BKS BKW Carbon Steel Seamless Tubes For Petroleum DIN 17175 19Mn5 15Mo3

Main Customers:



Chemical BKS BKW Carbon Steel Seamless Tubes For Petroleum DIN 17175 19Mn5 15Mo3Chemical BKS BKW Carbon Steel Seamless Tubes For Petroleum DIN 17175 19Mn5 15Mo3
