Cold Drawn Polished Stainless Steel Tube Bearing DIN 17230 100Cr2 GB ASTM

Brand Name:	JIANGSU HUACHENG
Model Number:	HC
MOQ:	5MT
Payment Terms:	30%T/T in advance or 100% L/C at sight
Supply Ability:	8000MT/Month

Detail Information

Product Description

Detail Information

Place of Origin:

Jiangsu China (Mainland)

Certification:

ISO9001 14001 BV TUV PED DNV etc

Features:

Thin Wall

Application:

Machinery

Certificate:

PED|ISO|BV|TUV

Delivery Condition:

Heat Treatment

Product Name:

Bearing Steel Tube

Section Shape:

Round

Standard:

GB|SKF|ASTM|DIN|JIS|BS

Technique:

Seamless|Hot Rolled|Cold Drawn

Packaging Details:

Exporting package/wooden box package/Or per customers’ requirement

Supply Ability:

8000MT/Month

Highlight:

steel round tube

carbon steel tubing

Product Description

Cold Drawn Polished Stainless Steel Tube Bearing DIN 17230 100Cr2 GB ASTM

Quick Detail:

Products: DIN 17230 100Cr2 Stainless Bearing Steel Tube
Standard: GB / SKF/ ASTM / DIN / JIS / BS
Size(mm):

OD:8mm ~ 101.6mm

WT:1.0mm ~ 10mm

Length: Fixed(6m,9m,12,24m) or normal length(5-12m)

Description:

Equivalent Grades:

Standard	GB/T 18254	CNS3014	GOST 801	JIS G4805	DIN 17230	ASTM A295
Grade	GCr4	SUJ1	SH4	SUJ1	100Cr2	K19526

Chemical Composition:

100Cr2	C	Si	Mn	P	S	Cr	Ni	Cu
%	0.90-1.25	0.15-0.35	0.25-0.45	≤0.030	≤0.025	0.40-0.60	<0.25	≤0.30

Raw Materail Processing:

EAF+LF+VOD+ Hot Rolled/forged+Cut+Heat Treatment(optional)+UT+package.

Delivery Condition:

Cold drawn, Hot rolled, Hot forged,Heat treatment.

Surface:

Black, Peeled (K12), Turned & Polished (H10, H11), Precision Ground (H9, H8).

Ultrasonic Test:

According to SEP 1921-84 3C/c.

High Carbon Chromium Alloy Bearing Steel Bar 100Cr2 Features:

1. Cleanliness and freedom from objectionable microscopic slag type inclusions.

2. Shallow decarburized surface.

3. Good surface quality.

4. Excellent micro-structure uniformity.

5. Tight tolerances, resulting in reduced machine time.

6. Wear resistance, long service life.

Applications:

1,Mainly used for manufacturing ordinary rolling bearing ring.

2,other applications such as used for automotive industry and bearings in rotating machinery.

Competitive Advantage:

Huacheng Pipe Making Company is one of the largest seamless steel pipe manufacturers in China.We’ve passed API 5L,API 5CT, PED, BV, TUV certification and ISO quality system certification.With good quality and competitive price, we believe we could be your reliable supplier.

Factroy Pictures:

Cold Drawn Polished Stainless Steel Tube Bearing DIN 17230 100Cr2 GB ASTM 0

Pipe & Tube Processing

Cold Drawn Polished Stainless Steel Tube Bearing DIN 17230 100Cr2 GB ASTM 1

Factory Equipments:

Cold Drawn Polished Stainless Steel Tube Bearing DIN 17230 100Cr2 GB ASTM 2

Production Line:

Cold Drawn Polished Stainless Steel Tube Bearing DIN 17230 100Cr2 GB ASTM 3

Quality Control:

Cold Drawn Polished Stainless Steel Tube Bearing DIN 17230 100Cr2 GB ASTM 4

Steel Pipe & Tube Application:

Cold Drawn Polished Stainless Steel Tube Bearing DIN 17230 100Cr2 GB ASTM 5

Package:

Export Standard / Wooden Box

Cold Drawn Polished Stainless Steel Tube Bearing DIN 17230 100Cr2 GB ASTM 6

Main Certificates:

PED ISO BV TUV etc.

Cold Drawn Polished Stainless Steel Tube Bearing DIN 17230 100Cr2 GB ASTM 7

Main Customers:

Cold Drawn Polished Stainless Steel Tube Bearing DIN 17230 100Cr2 GB ASTM 8
