ASTM A210 SA210M Weld Oil-dip Seamless Steel Tube Dimensions 12.7mm - 114.3mm
ASTM A210 is the standard covers seamless medium-carbon steel boiler and superheater tubes.
ASTM A210 also covers minimum-wall-thickness, tubing sizes, boiler flues including safe ends, arch and stay tubes.
ASTM A210 provides tensile and hardness properties but only applicable to certain size limitations. Material manufacturing shall be killed.
Tubes shall be made by seamless process, marked as either hot-finished or cold-finished.
Surface condition shall be specifically stated in the order.
Chemical composition shall conform to the requirements.
Elemental composition other than listed here shall not be permitted.
Tension test, flattening test, flaring test, hardness test, hydrostatic or nondestructive electric test shall be made on specimens.
Superheater tubes shall be formed without defects and shall withstand expansion, beading, forging, welding, and bending.
| Product Name | Seamless Medium-Carbon Steel Boiler and Superheater Tubes |
| Standard | ASTM A210/A210M (ASME SA210/SA210M) |
| Out Dimensions | 12.7mm-114.3mm |
| Wall Thickness | 0.8mm-15mm |
| Length | 5-25mm |
| Steel Grade | Grade A1; Grade C |
| Packing | Beveled/black painting/ plastic caps/ in bundles/ steel strips/ wooden protection |
| Inspection and Test | Chemical Composition Inspection, Mechanical Properties Test(Tensile Strength, Yield Strength,Elongation, Flaring, Flattening, Bending, Hardness, Impact Test),Surface and Dimension Test,Nodestructive Test, Hydrostatic Test. |
| Surface treatment |
Oil-dip, Varnish, Passivation, Phosphating, Shot Blasting |
| Mark | As requested |
| Delivery Condition | Annealed, Normalized, Normalized and Tempered |
| Applications | It is used for boiler and boiler flue tubes. Including safe end, vault and supporting tube and super heater min wall thickness seamless medium--carbon steel tube |
Chemical Requirements
|
STANDARD |
GRADE |
CHEMICAL COMPOSITION |
|||||||||
|
C |
Si |
Mn |
P |
S |
Cr |
Mo |
Cu |
Ni |
V |
||
|
ASTM A210 |
A-1 |
≤0.27 |
≥0.10 |
≤0.93 |
≤0.035 |
≤0.035 |
|
|
|
|
|
|
C |
≤0.35 |
≥0.10 |
0.291.06 |
≤0.035 |
≤0.035 |
|
|
|
|
|
|
Mechanical Properties
|
Grade |
Yield Strength (Mpa) |
Tensile Strength (Mpa) |
Elongation (%) |
|
A-1 |
≥255 |
≥415 |
30 |
|
C |
≥275 |
≥485 |
30 |
Wall Thickness Tolerance
|
|
OD |
WT |
WT Tolerance |
|
<=38.1 |
/ |
+20%,-0% |
|
|
>38.1 |
/ |
+20%,-0% |
Competitive Advantage
