EN 10305-4 E235 Seamless Steel Tubes , Cold Drawn Tubes For Hydraulic And Pneumatic Power Systems
Product Details
| Section Shape: | Round | OD: | 10~300mm |
|---|---|---|---|
| Surface Treatment: | Cold Drawn | Processing Service: | Welding, Decoiling, Punching, Cutting |
| Keyword: | Seamless Steel Pipe Tube | End Protector: | Plastic Pipe Cap |
| Tolerance: | ±1% | Grade: | EN 10305-4 E235 |
| Highlight |
seamless stainless steel tube,round steel tubes |
||
Product Description
EN 10305-4 E235 Seamless Steel Tubes , Cold Drawn Tubes For Hydraulic And Pneumatic Power Systems
Product Description:
type:
1. Seamless steel pipes can be divided into hot-rolled pipes, cold-rolled pipes, cold-drawn pipes, and extruded pipes according to different production methods.
2. According to the shape, there are round tubes and special-shaped tubes. In addition to square tubes and rectangular tubes, special-shaped tubes also include oval tubes, semicircular tubes, triangular tubes, hexagonal tubes, convex-shaped tubes, plum-shaped tubes, etc.
3. According to the different materials, it is divided into ordinary carbon structure pipe, low alloy structure pipe, high-quality carbon structure pipe, alloy structure pipe, stainless steel pipe, etc.
4. According to the special purpose, there are boiler tubes, geological tubes, oil tubes, etc.
|
Product Name
|
cold drawn seamless steel pipe
|
|
Material
|
EN 10305-4 E235
|
|
Standard
|
JIS,GB,ASTM,DIN
|
|
Technique
|
Cold Drawn
|
|
OD
|
10~300mm
|
|
Wall Thickness
|
1~30mm
|
|
Length
|
5.8m~12m/customized design
|
|
Surface Treatment
|
black painting, varnish, oil, galvanized, anti corrosion coatings
|
|
Packaging
|
1. Bundles with steel strip and woven sack wrapping
2. Bevelled end or plain end or warnished as per buyer's required. 3. Marking: as per customer's requests. |
|
MOQ
|
1 ton for normal material
|
|
Payment Terms
|
T/T,L/C etc
|
|
Testing
|
Chemical Component Analysis, Mechanical Properties, Ultrasonic inspection
Exterior Size Inspection, hydraulic testing etc. |
|
Application
|
Structure pipe; High and low pressure boiler tube; Liquid delivery; Seamless steel pipe for petroleum cracking ,Oil pipe,Gas pipe
|
|
Advantages
|
1.Reasonable price with excellent quality
2.Abundant stock and prompt delivery 3.Rich supply and export experience, sincere service 4.Reliable forwarder, 2-hour away from port. |
Chemical composition:
| Table 1- Chemical composition | ||||||
| Steel Grade | C% | Si% | Mn% | P% | S% | AL% |
| E215 | ≤0.10 | ≤0.05 | ≤0.7 | ≤0.025 | ≤0.025 | ≥0.025 |
| E235 | ≤0.17 | ≤0.35 | 0.4-1.2 | ≤0.025 | ≤0.025 | |
| E255 | ≤0.21 | ≤0.35 | 0.4-1.1 | ≤0.025 | ≤0.025 | |
| E355 | ≤0.22 | ≤0.55 | ≤1.6 | ≤0.025 | ≤0.025 | |
Mechanical properties:
| Table 2 - Mechanical properties at room temperature | |||||||||
| Delivery Condition | BK | BKW | GBK | NBK (N) | |||||
| Steel Grade | Rm | A % | Rm | A % | Rm | A % | Rm | ReH | A % |
| Mpa (Min) | (Min) | Mpa(Min) | (Min) | Mpa(Min) | (Min) | Mpa(Min) | Mpa(Min) | (Min) | |
| E215 | 430 | 8 | 380 | 12 | 280 | 30 | 290~430 | 215 | 30 |
| E235 | 480 | 6 | 420 | 10 | 315 | 25 | 340~480 | 235 | 25 |
| E255 | 580 | 5 | 520 | 8 | 390 | 21 | 440~570 | 255 | 21 |
| E355 | 640 | 4 | 580 | 7 | 450 | 22 | 490~630 | 355 | 22 |
Detailed Photo:
Factroy Pictures:
Pipe & Tube Processing:
Application:
Packaging & Shipping:
Certificates:
FAQ:
Q1: ARE YOU FACTORY OR TRADER?
A1: Wuxi Sylaith Special Steel Co.,Ltd is a manufacturer of steel pipe and tube since 2010. We've gained our Export Right and become an integrated company of industry and trade in order to satisfy buyer's multi-request on different material and products.
Q2: WHICH MATERIAL/PRODUCTS YOU CAN PROVIDE?
A2: Seamless Stainless Steel Pipe / Tube, Seamless Carbon Stainless Steel Pipe /Tube,Galvanized Steel Tube witn any Shape and Welded pipes can also be available
Q3: HOW TO GET A SAMPLE?
A3: FREE samples are available for your checking and testing. And to get free samples, you need to send us you detailed receiving address (including post code) and your DHL/FedEx/UPS account for collecting samples, courier cost will be paid in your side.
Q4. CAN YOU PRODUCE THE PRODUCTS ACCORDING TO MY OWN DRAWINGS?
A4: Yes, we can produce the products according to your drawings that will be most satisfy you.
Q5: HOW TO VISIT YOUR FACTORY?
A5: Most of the main cities have flights to Shanghai; you can take flight to Shanghai Putong/Hongqiao International Airport.
If you come from Hongkong, it will take 2 hours by flight (every day 5 flight around noon time).
