42CrMo4 Alloy Steel Cold Drawn Seamless Tube For Bearing And Chemical Equipment
Product Details
| Features: | Thick Wall|Thin Wall | Application: | Machinery|Oil Cylinder Tube|Building|Construction |
|---|---|---|---|
| Material: | Carbon Steel|Alloy Steel | Product Name: | Cold Drawn Seamless Tube|Seamless Steel Tubes|Galvanized Steel Tube |
| Section Shape: | Round | Processing Service: | Bending, Welding, Cutting |
| Delivery Condition: | Hot Rolled Or Forged, Black Or Machined, Annealed Or QT | Technique: | Seamless|Cold Drawn|ERW |
| Highlight |
42CrMo4 cold drawn seamless tube,Alloy Steel cold drawn seamless tube,cold drawn steel tube For Bearing |
||
Product Description
42CrMo4 Alloy Steel Cold Drawn Seamless Tube For Bearing And Chemical Equipment
Description:
Product name:
42CrMo4 Alloy Steel Cold Drawn Seamless Tube For Bearing And Chemical Equipment
Standard executived: ASTM / DIN / EN / GOST / SAE / JIS etc
(ASTM A179,ASTM A199, ASTM A200, ASTM A213, DIN 17175,JIS G3462,JIS G3458 )
Outside diameter:25.4mm
Wall Thickness:1.65mm
Length:6m-25m,also can be manufactured according to customers' requirements
Type:Cold Drawn or ERW
Ends:Plain ends or bevel ends
Delivery Conditions: BK,BKS,BKW,NBK,GBK( As drawn, quenched and tempered, normalized, annealed, stress-relieved)As different requirements,It including pickling,etc. AS per Standard.
Coating for protection:black painting,anti-rust oiled or varnish,also can be required according to customers' requirements
Factory test and other terms:
1.Hydrostatic or Nondestructive Electric Test
2.Heat Treatment: according to Standard
3.Surface Condition:According to Standard.
4.Grain Size:According to standard
5.Sampling:flattening,flaring,grain size,Marking6.we provide bevel end,plastic cap, varnish coating, oiled or black painted to prevent rustand other packing
service.
Main Specification Details:
| Standard | API, ASTM, BS, DIN, GB, JIS |
| Outer Diameter | 21.3mm-660mm |
| Wall Thickness | 0.5mm-20mm |
| Dia Tolerance | Control with in the standard, OD:±1%, WT:±10% |
Materials |
10#, 20#, 45#, Q235, Q345, Q195, Q215, SS400, ASTM A53/A106/A178/A333/A335, ST37, ST37-2, DIN 1629 ST35, ST45, ST52, DIN 17175 ST35.8, DIN 17175 19Mn5, 16Mn, Q345B, T1, T2, T5, T9, T11, T12, T22, T91, T92, P1, P2, P5, P9, P11,P12, P22, P91, P92, 42CrMO4, Cr5Mo, 10CrMo910, 12CrMo, 13CrMo44, 30CrMo, GR.1, GR.3, GR.6, GR.7, Gr.B, X42, X46, X52, X60, X65, X70, X80, X100 |
| Zinc coating | Pre galvanized steel pipe: 60-150g/m² Hot dipped galvanized steel pipe: 200-400g/m² |
| Type of pipe coating | Epoxy powder |
| Inspection | ISO, BV, SGS, MTC |
| Packing | Steel strip packed. Standard Export Seaworthy Package. Suit forall kinds of transport,or as required |
| Application | Accessorize, machinery parts, structure steel pipe, piling pipe, sewage and clear water transportation, Line pipe for petroleum and so on |
| MOQ | 5metric ton,sample order accepted |
| Shipment time | Within 7-10 workdays after receiving deposit or L/C |
| Market | Southeast Asia, Middle East, Africa, Europe, South American and so on |
Delivery condition:
|
Designation |
Symbol |
Description |
|
Cold finished (hard) |
BK |
Tubes do not undergo heat treatment following the final cold forming and, thus, have a rather high resistance to deformation. |
|
Cold finished (soft) |
BKW |
The final heat treatment is followed by cold drawing involving limited deformation. Appropriate further processing allows a certain degree of cold forming. (e.g. bending, expanding). |
|
Cold finished and stress-relieved |
BKS |
Heat treatment is applied following the last cold forming process. Subject to appropriate processing conditions, the increase in the residual stresses involved enables both forming and machining to a certain degree. |
|
Annealed |
GBK |
The last cold forming process is followed by annealing in a controlled atmosphere. |
|
Normalized |
NBK |
The last cold forming process is followed by annealing above the upper transformation point in a controlled atmosphere. |
All other tubes applicable for boiler and heat exchanger tube we can produce
| Descriptions | Grades | Standard | Specification (OD*WT)mm |
Usage |
| Structural steel pipe | 20# 35# 45# Q345B, 16Mn, Q345B-E, 20Mn2, 25Mn, 30Mn2, 40Mn2, 45Mn2, SAE1018, SAE1020, SAE1518, SAE1045. | GB/T8162-2008 | 6-1020*1.5-100 | For commom structure |
| Fluid steel pipe | 10#, 20#, ASTM A106, A210, A53, 16Mn, Q345A.B.C.D.E, Q295B.C.D.E | GB/T8163-2008 | 8-630*1.0-40 | Fluid feeding |
| High pressure boiler pipe | 20G, 15MnG, 20MnG, 15CrMoG, 12Cr1MoVG, St35.8, St45, SA106b, SA106c, SA210a, SA210c, A335P2, P11, P12, P22, P91, P92, A213 T2,T9, T11, T12, T22, T23, T91 | GB/5310-2008, ASTM A 106-99, DIN 17175-79 |
14-630*2-80 | Temperature-resistant seamless steel pipe far high-pressure boiler |
| Oil casing pipe | API SPEC 5CT J55, K55, N80, L80, C90, C95, P110 | API SPEC 5CT, SY/T6194-96, GB/T222-84, | 10-530*1.5-36 | Boiler pipes for refinery,heatexchangeing pipes,seamless steel pipes for pipeline |
| Pipeline | API SPEC 5L, X42, X52, X60, X65,X70,X80 ASTM A53, ASTM A106, ASTM A333, BS301, BS3602, BS3603, BS3604, PSL1, PSL2, DNV-OS-F101, CSA-Z245 |
API SPEC 5L, ISO 3183, GB/T 9711 | 60-630*1.5-40 | Carrying gas,water or oil in the industries of petroleum and natural gas |
| Alloy steel pipe | 4140, 42CrMo, 32CrMo, 15CrMo, Cr5Mo, 13CrMo44, 12Cr1MoV P22 T91,P91,P9, T9, Wb36 | GB5310-95, GB9948-88, ASTM A335/A335M, ASTM A213/213M, DIN17175-79, JISG3467-88, JISG3458-88 |
16-824*2-100 | The seamless steal pipes features resistance to high presure,high/low temperature and corrosion ano is used in the industries of petroleum, chemical engineering and. Electric pwer as well as boiler |
| Hydraulic prop pipe | 20#, 45#, 27SiMn, 30CrMoSiA | GB/T17396-2009 | 70-377*9-40 | Coal mine hydraulic support and pillar cylinder, column, can also be used for other hydraulic cylinder, column |
Applications:
1,For evaporator, heat exchangers, condensers, heat transfer equipment and similar pipes.
2,Widely used in the mechanical treatment field, petrochemical industry, transport and construction field
3,Ordinary structural purposes and mechanic structural purposes, for example in construction field, fulcrum bearing etc;
4,The transportation of fluids in the projects and big equipments, for example transport of water, oil, gas etc
5,Can be used in low and medium pressure boiler for the transportation of fluids, for example steam tube, big smoke tube, small smoke tube, generating tube etc
Competitive Advantage:
Huacheng Industry Pipe Making Corporation
Asia Leading Steel Pipe & Tube Manufacturer with more than 250,000Tons/Year, >60% shipped to more than 35 Countries.We aims at manufacturing quality pipes & tubes with reasonable and competitive price, good quality for our global customers.
Factroy Pictures:
Pipe & Tube Processing
Factory Equipments:
Production Line:
Quality Control:
Steel Pipe & Tube Application:
Package:
Export Standard / Wooden Box
Main Certificates:
PED ISO BV TUV etc.
Main Customers:
